Cisco C9500-16X-A
Cisco · Model C9500-16X-A
Condition: Not stated on import · Availability: Quote on request
- Ports
- 16
- Speed
- 10G
- PoE
- Non-PoE
- Capacity
- Up to 480 Gbps full-duplex
Enterprise campus core where uplink density is the primary constraint. Campus core or collapsed-core where northbound uplinks are the constraint.
Datasheet: not attached yet.
Product overview
Cisco C9500-16X-A is positioned as a Cisco Catalyst 9500 SKU where uplink density and tabled capacity dominate over PoE. Switching capacity on record: Up to 480 Gbps full-duplex. Campus core or collapsed-core where northbound uplinks are the constraint.
Cisco C9500-16X-A
Cisco C9500-16X-A: Cisco C9500-16X-A is positioned as a Cisco Catalyst 9500 SKU where uplink density and tabled capacity dominate over PoE. Switching capacity on record: Up to 480 Gbps full-duplex. Key published facts — Published downlink: 16 × 1/10 Gbps SFP+ + 1 NM slot; Published uplink: 1 × C9500-NM-8X or C9500-NM-2Q (included); PoE state: Non-PoE.
Product Overview
Cisco C9500-16X-A is positioned as a Cisco Catalyst 9500 SKU where uplink density and tabled capacity dominate over PoE. Switching capacity on record: Up to 480 Gbps full-duplex. Campus core or collapsed-core where northbound uplinks are the constraint.
Key Features
- Published downlink: 16 × 1/10 Gbps SFP+ + 1 NM slot
- Published uplink: 1 × C9500-NM-8X or C9500-NM-2Q (included)
- PoE state: Non-PoE
- Switching capacity: Up to 480 Gbps full-duplex
- Forwarding rate: Up to 360 Mpps (64-byte packets)
- Stacking / HA note: StackWise Virtual for active-active resiliency
- Network role: core
Technical Specs
- downlink: 16 × 1/10 Gbps SFP+ + 1 NM slot
- uplink: 1 × C9500-NM-8X or C9500-NM-2Q (included)
- poe: Non-PoE
- switching_capacity: Up to 480 Gbps full-duplex
- forwarding_rate: Up to 360 Mpps (64-byte packets)
- dimensions: 1.73″ × 17.5″ × 21.52″ (43.9 × 444.5 × 546.6 mm)
- power: 1 × PWR-C4-950WAC-R (950 W AC), front-to-back airflow; 1+1 redundancy supported
- weight: 23.6 lb (10.7 kg)
- stacking: StackWise Virtual for active-active resiliency
Deployment Scenarios
Enterprise campus core where uplink density is the primary constraint. Campus core or collapsed-core where northbound uplinks are the constraint.
Technical Selection Notes
Treat HA claims only when the source table states redundant supervisor/PSU language. Published mix: 16 × 1/10 Gbps SFP+ + 1 NM slot / 1 × C9500-NM-8X or C9500-NM-2Q (included).
Not Recommended For
High-density 25/100G server leaf unless those optics appear on this PID.
Related Model Comparison
| Model | Ports | Layer | PoE | Use case |
|---|---|---|---|---|
| C9500-16X-A | 16 × 1/10 Gbps SFP+ + 1 NM slot | core | Non-PoE | Current PID |
| C9500-16X | core | Non-PoE | C9500-16X sits in Cisco Catalyst 9500 as a campus/core SKU: uplink density and tabled capacity matter more than PoE. | |
| C9500-16X-E | 16 × 10 Gbps SFP+ | core | Non-PoE | Cisco C9500-16X-E is positioned as a Cisco Catalyst 9500 SKU where uplink density and tabled capacity dominate over PoE. Switching capacity on record: Up to 480 |
| C9500-24X | core | Non-PoE | C9500-24X sits in Cisco Catalyst 9500 as a campus/core SKU: uplink density and tabled capacity matter more than PoE. |
FAQ
What network role does C9500-16X-A fit?
Cisco C9500-16X-A is positioned as a Cisco Catalyst 9500 SKU where uplink density and tabled capacity dominate over PoE. Switching capacity on record: Up to 480 Gbps full-duplex.
What downlink ports does C9500-16X-A publish?
16 × 1/10 Gbps SFP+ + 1 NM slot
What uplink option is listed for C9500-16X-A?
1 × C9500-NM-8X or C9500-NM-2Q (included)
Can C9500-16X-A support PoE endpoints?
Published PoE state for this PID: Non-PoE. Size devices against the listed budget only.
What switching capacity is verified for C9500-16X-A?
Up to 480 Gbps full-duplex
What scenarios suit Cisco C9500-16X-A?
Campus core or collapsed-core where northbound uplinks are the constraint.
Related Products
Request a quote — availability is quote on request.
Key features
Published downlink: 16 × 1/10 Gbps SFP+ + 1 NM slot Published uplink: 1 × C9500-NM-8X or C9500-NM-2Q (included) PoE state: Non-PoE Switching capacity: Up to 480 Gbps full-duplex Forwarding rate: Up to 360 Mpps (64-byte packets) Stacking / HA note: StackWise Virtual for active-active resiliency Network role: core
Technical specifications
| Model | C9500-16X-A |
|---|---|
| Manufacturer model | C9500-16X-A |
| Display model | C9500-16X-A |
| Layer | core |
| Port count | 16 |
| Downlink ports | 16 × 1/10 Gbps SFP+ + 1 NM slot |
| Uplink ports | 1 × C9500-NM-8X or C9500-NM-2Q (included) |
| Port type | SFP+ |
| Port speed | 10G |
| Switching capacity | Up to 480 Gbps full-duplex |
| Forwarding rate | Up to 360 Mpps (64-byte packets) |
| PoE | Non-PoE |
| Stacking | StackWise Virtual for active-active resiliency |
| Power supply | 1 × PWR-C4-950WAC-R (950 W AC), front-to-back airflow; 1+1 redundancy supported |
| Dimensions | 1.73″ × 17.5″ × 21.52″ (43.9 × 444.5 × 546.6 mm) |
| Weight | 23.6 lb (10.7 kg) |
| Condition | Not stated on import |
| Availability | Quote on request |
Applications
Enterprise campus core where uplink density is the primary constraint. Campus core or collapsed-core where northbound uplinks are the constraint.
Networking / deployment scenarios
Enterprise campus core where uplink density is the primary constraint. Campus core or collapsed-core where northbound uplinks are the constraint.
FAQ
What network role does C9500-16X-A fit?
Cisco C9500-16X-A is positioned as a Cisco Catalyst 9500 SKU where uplink density and tabled capacity dominate over PoE. Switching capacity on record: Up to 480 Gbps full-duplex.
What downlink ports does C9500-16X-A publish?
16 × 1/10 Gbps SFP+ + 1 NM slot
What uplink option is listed for C9500-16X-A?
1 × C9500-NM-8X or C9500-NM-2Q (included)
Can C9500-16X-A support PoE endpoints?
Published PoE state for this PID: Non-PoE. Size devices against the listed budget only.
What switching capacity is verified for C9500-16X-A?
Up to 480 Gbps full-duplex
What scenarios suit Cisco C9500-16X-A?
Campus core or collapsed-core where northbound uplinks are the constraint.
Datasheet download
No datasheet file is attached yet. Request documentation with your RFQ if needed.
